Power Amplifier Ahuja SPA-25000
Ahuja SPA-25000
HIGH WATTAGE PA POWER AMPLIFIERS
2500 WATTS
₹62,000.00
Share :
Product Details
- Super high power single channel PA booster amplifier, specially designed for big installations where large number of speakers are required. Class H operation for optimum efficiency
- Line Input 200mV/1V switchable for connecting a mixer or another amplifier.
- 100V input for connecting to another amplifier 100V output.
- Built-in circuit for protection against overload, short circuit and temperature.
- Built-in protection against overvoltage in AC mains supply which is specially useful while operating on a genset.
- Box Speaker/Driver Unit selector switch. Bass boost defeated at Driver Unit position for safer operation of driver units.
- 100V/70V, 4W and 2W power outputs
- Ideal for large installations where very high power output is required.
Specifications
All
- Power Output:3000W Max. | 2500W RMS at 10% THD 2300W RMS at 5% THD | 2150W RMS at 2% THD
- Output Regulation:≤ 2 dB | no load to full load at 1kHz
- Input Channels:1 × Line 200mV/20kΩ balanced | 10kΩ unbalanced | 1 × Line 1V/20kΩ balanced | 10kΩ unbalanced | 1 × 100V Input/50kΩ
- Frequency Response:50-15000Hz ±3dB
- Signal to Noise Ratio:75dB
- Tone Controls:Bass: ±10dB at 100Hz | Treble: ±10dB at 10kHz
- Speaker Outputs:2Ω | 4Ω | 70V & 100V
- Power Supply:AC: 220-240V 50/60Hz
- Power Consumption:AC: 3400VA
