Mixer Ahuja DA-80
Ahuja DA-80
PA EFFECT PROCESSORS
AC & 24V DC Operation
₹5,250.00
Share :
Product Details
- Sleek & compact 8-channel line signal splitter suitable for various large installations & PA applications. Recommended for use when a single programme source has to feed several amplifiers. Avoids signal loading and related distortion problems.
- Accepts line level Stereo/Mono input.
- Provides four line level stereo outputs or eight line level mono outputs.
- Individual volume controls for input and eight output channels.
- Clip LED for setting optimum distortion free input levels.
- Operates on AC mains and 24V DC Car Battery.
- 19” rack mountable in 1U space and also usable as a table top unit.
Specifications
all
- Frequency Response:20-20000Hz (±3dB)
- SIGNAL TO NOISE RATIO:70dB
- POWER SUPPLY:AC: 220-240V 50/60Hz DC: 24V (2×12V Car Battery)
- Outputs:8 × 200mV/470Ω
- Distortion:<0.1%
- Input Channels:2 × 100mV/47kΩ
- Dimensions:W483 × H43 × D178 mm
- Weight:2.80kg
